XIP4200H: High-speed ECC Accelerator

Overview Key Features Offering Brief What's Included Ordering Information Markets

Xiphera Ltd.

Select

Xiphera’s NIST Curves high-speed accelerator for ECDH/ECDSA provide cutting-edge security solutions designed for robust public-key operations, including encryption, digital signatures, and key exchanges. These cores are optimised for performance in FPGA implementations, offering versatile functionality across various cryptographic protocols.

View Partner Website

Partner Product Page

Contact Now

Contact Xiphera Ltd.

LeadSource

ASAP Account ID

Record Type Name

Key Features

High Speed: XIP4200H is optimized for high speed. For example, a key generation on NIST P-256 requires approximately 180k clock cycles, and XIP4200H can compute over a thousand operations per second on modern high-speed FPGAs and ASICs.
Versatile Curve Support: XIP4200H natively supports all NIST P curves [2] within a single IP core instance. Customer-speci€ed curves can be added into the set of supported curves.
Secure Architecture: Execution time and pattern of operations are independent of the secret values providing full protection against timing-based side-channel attacks. XIP4200H includes hardened protections against multi-trace side-channel attacks (for example, DPA). XIP4200H is fully RTL-based with no embedded software or CPU components.
Standard Compliance: XIP4200H is compliant with FIPS 186-5 [3] and SP 800-56A [1]. XIP4200H can be used as a part of numerous public-key systems and protocols including IKEv2 [5] [8] [4] and TLS 1.3 [7].
Easy Integration: The simple 32-bit interface supports easy system integration.

Offering Brief

Device Family	Arria® 10 SX SoC FPGA, Cyclone® IV GX FPGA, Agilex® 5 FPGAs and SoC FPGAs E-Series, MAX® 10 FPGA, Cyclone® V SX SoC FPGA, Arria® V GZ FPGA, Agilex® 9 FPGAs and SoC FPGAs Direct RF-Series, Agilex® 7 FPGAs and SoC FPGAs I-Series, Arria® V SX SoC FPGA, Stratix® 10 DX FPGA, Stratix® 10 SX SoC FPGA, Agilex® 7 FPGAs and SoC FPGAs M-Series, Cyclone® V GT FPGA, Arria® 10 GT FPGA, Arria® V ST SoC FPGA, Arria® 10 GX FPGA, Stratix® 10 TX FPGA, Cyclone® V SE SoC FPGA, Stratix® IV E FPGA, Stratix® IV GX FPGA, Arria® V GX FPGA, Agilex® 3 FPGAs and SoC FPGAs C-Series, Cyclone® V GX FPGA, Stratix® V GS FPGA, Stratix® V GX FPGA, Cyclone® V ST SoC FPGA, Agilex® 5 FPGAs and SoC FPGAs D-Series, Stratix® 10 GX FPGA, Arria® V GT FPGA, Cyclone® 10 LP FPGA, Agilex® 7 FPGAs and SoC FPGAs F-Series, Cyclone® 10 GX FPGA, Stratix® 10 AX SoC FPGA, Stratix® III FPGA
Offering Status	Production
Integrated Testbench	Yes
Evaluation License	Yes
Design Examples Available	Yes
Demo	No
Compliance	Yes
Latest Quartus Version Supported	25.1.1
Development Language	Encrypted Verilog, Verilog
