XIP4001C: Curve25519 Key Exchange IP Core

Overview Key Features Offering Brief What's Included Ordering Information Markets

Xiphera Ltd.

Select

Curve25519 compact IP core offers public-key exchange. The IP core is optimised for both performance and resource efficiency in both FPGA and ASIC implementations, offering versatile functionality across various cryptographic protocols.

View Partner Website

Partner Product Page

Contact Now

Contact Xiphera Ltd.

LeadSource

ASAP Account ID

Record Type Name

Key Features

Minimal Resource Requirements: The entire XIP4001C requires less than 1k Logic Elements and uses only 1-2 multipliers/DSP Blocks2 and one internal memory block in a typical FPGA implementation.
Constant Latency: The execution time of XIP4001C is independent of the key value, and consequently provides protection against timing-based side-channel attacks.
Performance: Despite its small size, XIP4001C can support more than 100 key exchange operations per second.
Standard Compliance: XIP4001C is compliant with RFC7748 [1], and can be used as a part of many public-key protocols including IKEv2 (RFC 8031) [3] and TLS 1.3 (RFC 8446) [4].

Offering Brief

Device Family	Arria® 10 SX SoC FPGA, Cyclone® IV GX FPGA, Agilex® 5 FPGAs and SoC FPGAs E-Series, MAX® 10 FPGA, Cyclone® V SX SoC FPGA, Arria® V GZ FPGA, Agilex® 9 FPGAs and SoC FPGAs Direct RF-Series, MAX® V CPLD, Agilex® 7 FPGAs and SoC FPGAs I-Series, Arria® V SX SoC FPGA, Stratix® 10 DX FPGA, Stratix® 10 SX SoC FPGA, Agilex® 7 FPGAs and SoC FPGAs M-Series, Cyclone® V GT FPGA, Arria® 10 GT FPGA, Arria® V ST SoC FPGA, Arria® 10 GX FPGA, Stratix® 10 TX FPGA, Cyclone® V SE SoC FPGA, Stratix® IV E FPGA, Stratix® IV GX FPGA, Arria® V GX FPGA, Cyclone® V E FPGA, Agilex® 3 FPGAs and SoC FPGAs C-Series, Cyclone® V GX FPGA, Stratix® V GS FPGA, Stratix® V GX FPGA, Cyclone® V ST SoC FPGA, Agilex® 5 FPGAs and SoC FPGAs D-Series, Stratix® 10 GX FPGA, Arria® V GT FPGA, Cyclone® 10 LP FPGA, Agilex® 7 FPGAs and SoC FPGAs F-Series, Cyclone® 10 GX FPGA, Stratix® 10 AX SoC FPGA, Cyclone® IV E FPGA, Stratix® III FPGA
Offering Status	Production
Integrated Testbench	No
Evaluation License	No
Design Examples Available	No
Demo	No
Compliance	No
Latest Quartus Version Supported	25.1.1
Development Language	Encrypted VHDL, VHDL
