XIP3327C: Compact HKDF/HMAC/SHA-256/SHA-512 IP core

Overview Key Features Offering Brief What's Included Ordering Information Markets

Xiphera Ltd.

Select

XIP3327C from Xiphera is a versatile Intellectual Property (IP) core designed for SHA-256 and SHA-512 cryptographic hash functions with extended support for HMAC message authentication code and HKDF key derivation function that are based on using SHA-256. SHA-256 and SHA512 are among the most commonly used hash functions and are used in numerous cryptographic applications. XIP3327C is optimized for low FPGA resource requirements.

View Partner Website

Partner Product Page

Contact Now

Contact Xiphera Ltd.

LeadSource

ASAP Account ID

Record Type Name

Key Features

Standard Compliance: XIP3327C is compliant with NIST FIPS 180-4 Secure Hash Standard (SHS) [2], FIPS 198-1 The Keyed-Hash Message Authentication Code (HMAC) [1], and RFC 5869 HMAC-based Extract-and-Expand Key Derivation Function (HKDF) [3]. Consequently, XIP3327C can be used in multiple cryptographic applications.
Versatility: XIP3327C supports the widely used cryptographic hash functions SHA-256 and SHA-512. It also has native support for commonly used message authentication code (HMAC) based on SHA-256 and key derivation function (HKDF) based on HMAC-SHA-256. This allows using XIP3327C for multiple cryptographic functions —for example, TLS 1.3 [4] —more easily and efficiently than an IP core that supports only SHA-256 or SHA-512.
Constant Latency: The execution time of XIP3327C is independent of the message and key values (apart from message length), and consequently provides protection against timingbased side-channel attacks.
Compact Size: XIP3327C has compact size (for example, 1199 LUTs and, 2/1 RAMB36/18 in Xilinx® Zynq-7000® family) permitting integration into resource constrained FPGA designs.

Offering Brief

Device Family	Arria® 10 SX SoC FPGA, Cyclone® IV GX FPGA, Agilex® 5 FPGAs and SoC FPGAs E-Series, MAX® 10 FPGA, Cyclone® V SX SoC FPGA, Arria® V GZ FPGA, Agilex® 9 FPGAs and SoC FPGAs Direct RF-Series, MAX® V CPLD, Agilex® 7 FPGAs and SoC FPGAs I-Series, Arria® V SX SoC FPGA, Stratix® 10 DX FPGA, Stratix® 10 SX SoC FPGA, Agilex® 7 FPGAs and SoC FPGAs M-Series, Cyclone® V GT FPGA, Arria® 10 GT FPGA, Arria® V ST SoC FPGA, Arria® 10 GX FPGA, Stratix® 10 TX FPGA, Cyclone® V SE SoC FPGA, Stratix® IV E FPGA, Stratix® IV GX FPGA, Arria® V GX FPGA, Cyclone® V E FPGA, Agilex® 3 FPGAs and SoC FPGAs C-Series, Cyclone® V GX FPGA, Stratix® V GS FPGA, Stratix® V GX FPGA, Cyclone® V ST SoC FPGA, Agilex® 5 FPGAs and SoC FPGAs D-Series, Stratix® 10 GX FPGA, Arria® V GT FPGA, Cyclone® 10 LP FPGA, Agilex® 7 FPGAs and SoC FPGAs F-Series, Cyclone® 10 GX FPGA, Stratix® 10 AX SoC FPGA, Cyclone® IV E FPGA, Stratix® III FPGA
Offering Status	Production
Integrated Testbench	Yes
Evaluation License	Yes
Design Examples Available	Yes
Demo	No
Compliance	Yes
Latest Quartus Version Supported	25.1.1
Development Language	Encrypted VHDL, VHDL
