XIP3030C: A Compact Versatile Core for SHA-3-224/256/384/512 and (c)SHAKE-128/

Overview Key Features Offering Brief What's Included Ordering Information Markets

Xiphera Ltd.

Select

Compact SHA-3 IP core provide versatile functionality for various applications, from data integrity verification to password security. Xiphera’s SHA-3 IP cores support SHA3-224, SHA3-256, SHA3-384, SHA3-512, and related functions such as SHAKE, cSHAKE, KMAC, TupleHash, and ParallelHash.

View Partner Website

Partner Product Page

Contact Now

Contact Xiphera Ltd.

LeadSource

ASAP Account ID

Record Type Name

Key Features

Minimal Resource Requirements: XIP3030C requires 1394 ALMs with Altera Cyclone® 10 LP or 1003 6-input LUTs with AMD Zynq-7000® and use only some internal memory blocks in a typical FPGA implementation.
Versatile Algorithm Support: XIP3030C supports SHA-3-224/256/384/512, SHAKE-128/256, and cSHAKE-128/256. That is, XIP3030C covers all algorithms defined in [1] and also all algorithms included in [2] are supported via cSHAKE.
Secure Architecture: The execution time of XIP3030C is independent of the input values and, consequently, provides full protection against timing-based side-channel attacks.
Standard Compliance: XIP3030CiscompliantwithFIPS202[1] andSP800-185[2]. XIP3030C can be used as a part of numerous systems and protocols that require SHA-3 or its derivatives.
Easy Integration: The 64-bit interface of XIP3030C supports easy integration to various systems.

Offering Brief

Device Family	Arria® 10 SX SoC FPGA, Cyclone® IV GX FPGA, Agilex® 5 FPGAs and SoC FPGAs E-Series, MAX® 10 FPGA, Cyclone® V SX SoC FPGA, Arria® V GZ FPGA, Agilex® 9 FPGAs and SoC FPGAs Direct RF-Series, MAX® V CPLD, Agilex® 7 FPGAs and SoC FPGAs I-Series, Arria® V SX SoC FPGA, Stratix® 10 DX FPGA, Stratix® 10 SX SoC FPGA, Agilex® 7 FPGAs and SoC FPGAs M-Series, Cyclone® V GT FPGA, Arria® 10 GT FPGA, Arria® V ST SoC FPGA, Arria® 10 GX FPGA, Stratix® 10 TX FPGA, Cyclone® V SE SoC FPGA, Stratix® IV E FPGA, Stratix® IV GX FPGA, Arria® V GX FPGA, Cyclone® V E FPGA, Agilex® 3 FPGAs and SoC FPGAs C-Series, Cyclone® V GX FPGA, Stratix® V GS FPGA, Stratix® V GX FPGA, Cyclone® V ST SoC FPGA, Agilex® 5 FPGAs and SoC FPGAs D-Series, Stratix® 10 GX FPGA, Arria® V GT FPGA, Cyclone® 10 LP FPGA, Agilex® 7 FPGAs and SoC FPGAs F-Series, Cyclone® 10 GX FPGA, Stratix® 10 AX SoC FPGA, Cyclone® IV E FPGA, Stratix® III FPGA
Offering Status	Production
Integrated Testbench	No
Evaluation License	No
Design Examples Available	No
Demo	No
Compliance	No
Latest Quartus Version Supported	25.1.1
Development Language	Encrypted VHDL, VHDL
