XIP2201B: ASCON, A Lightweight Cryptographic Suite for AEAD and Hashing, balanced (XIP22

Overview Key Features Offering Brief What's Included Ordering Information Markets

Xiphera Ltd.

Select

Ascon IP core implements a lightweight, sponge-based encryption algorithm, being ideal for constrained environments such as IoT devices. Ascon performs three cryptographic primitives: Authenticated Encryption with Associated Data (AEAD), hashing, and extendable output function (XOF), offering a smaller alternative for e.g. AES-GCM and SHA-3 IP cores.

View Partner Website

Partner Product Page

Contact Now

Contact Xiphera Ltd.

LeadSource

ASAP Account ID

Record Type Name

Key Features

Small Resource Requirements: XIP2201B requires only approximately 2100 Logic Elements (LEs) on a typical FPGA implementation and can still provide over 2 Gbps throughput.
Versatile Algorithm Support: XIP2201B supports ASCON-128/128a/80pq/Hash/Hasha as well as XOF and XOFa. In other words, XIP2201B supports all parameterized algorithms given in [2].
Secure Architecture: The execution time of XIP2201B is independent of the input values and, consequently, provides full protection against timing-based side-channel attacks.
Standard Compliance: XIP2201B is compliant with Ascon specification 1.2 (31.05.2021) [2] which is the version that was selected to be standardized by NIST [1]. Xiphera commits to update XIP2201B when the standardization proceeds to newer versions.
Easy Integration: The 64-bit interface of XIP2201B supports easy integration to various systems.

Offering Brief

Device Family	Arria® 10 SX SoC FPGA, Cyclone® III FPGA, Cyclone® IV GX FPGA, Agilex® 5 FPGAs and SoC FPGAs E-Series, MAX® 10 FPGA, Cyclone® V SX SoC FPGA, Arria® V GZ FPGA, Agilex® 9 FPGAs and SoC FPGAs Direct RF-Series, MAX® V CPLD, Agilex® 7 FPGAs and SoC FPGAs I-Series, Arria® V SX SoC FPGA, Stratix® 10 DX FPGA, Stratix® 10 SX SoC FPGA, Agilex® 7 FPGAs and SoC FPGAs M-Series, Cyclone® V GT FPGA, Arria® 10 GT FPGA, Arria® V ST SoC FPGA, Arria® 10 GX FPGA, Stratix® 10 TX FPGA, Cyclone® V SE SoC FPGA, Stratix® IV E FPGA, Stratix® IV GX FPGA, Arria® V GX FPGA, Cyclone® V E FPGA, Agilex® 3 FPGAs and SoC FPGAs C-Series, Cyclone® V GX FPGA, Stratix® V GS FPGA, Stratix® V GX FPGA, Cyclone® V ST SoC FPGA, Agilex® 5 FPGAs and SoC FPGAs D-Series, Stratix® 10 GX FPGA, Arria® V GT FPGA, Cyclone® 10 LP FPGA, Agilex® 7 FPGAs and SoC FPGAs F-Series, Cyclone® 10 GX FPGA, Stratix® 10 AX SoC FPGA, Cyclone® IV E FPGA, Stratix® III FPGA
Offering Status	Production
Integrated Testbench	Yes
Evaluation License	Yes
Design Examples Available	Yes
Demo	No
Compliance	Yes
Latest Quartus Version Supported	25.1.1
Development Language	Encrypted Verilog, Verilog
