Extreme speed AES256-GCM core implements the Advanced Encryption Standard (AES) in Galois Counter Mode (GCM) with up to 800G linerate. AES-GCM is a widely used cryptographic algorithm for Authenticated Encryption with Associated Data (AEAD) purposes, providing both data confidentiality and authenticity.

View Partner Website

Partner Product Page

Contact Now

Contact Xiphera Ltd.

LeadSource

ASAP Account ID

Record Type Name

Key Features

High Security: XIP1113E implements AES256-GCM authenticated encryption as defined in the NIST standards FIPS PUB 197 [1] and Special Publication 800-38D [2], and offers a security level of 256 bits.
Extremely High Throughput: XIP1113E offers extremely high throughput for a single stream of data as it processes one 32/64/128-byte block per clock cycle and has a high maximum clock frequency. The IP cores of XIP1113E achieve throughputs of hundreds of Gbps depending on the target FPGA.
Constant Latency: XIP1113E offers constant latency for every data block and has a deter- ministic latency that facilitates an easy integration to various systems.
Secure Design: XIP1113E executes encryption and decryption in constant time (that is, in- dependent of the value of the key), and therefore provides full protection against timing side-channel attacks.

Offering Brief

Device Family	Arria® 10 SX SoC FPGA, Cyclone® IV GX FPGA, Agilex® 5 FPGAs and SoC FPGAs E-Series, MAX® 10 FPGA, Cyclone® V SX SoC FPGA, Arria® V GZ FPGA, Agilex® 9 FPGAs and SoC FPGAs Direct RF-Series, Agilex® 7 FPGAs and SoC FPGAs I-Series, Arria® V SX SoC FPGA, Stratix® 10 DX FPGA, Stratix® 10 SX SoC FPGA, Agilex® 7 FPGAs and SoC FPGAs M-Series, Cyclone® V GT FPGA, Arria® 10 GT FPGA, Arria® V ST SoC FPGA, Arria® 10 GX FPGA, Stratix® 10 TX FPGA, Cyclone® V SE SoC FPGA, Stratix® IV E FPGA, Stratix® IV GX FPGA, Arria® V GX FPGA, Agilex® 3 FPGAs and SoC FPGAs C-Series, Cyclone® V GX FPGA, Stratix® V GS FPGA, Stratix® V GX FPGA, Cyclone® V ST SoC FPGA, Agilex® 5 FPGAs and SoC FPGAs D-Series, Stratix® 10 GX FPGA, Arria® V GT FPGA, Cyclone® 10 LP FPGA, Agilex® 7 FPGAs and SoC FPGAs F-Series, Cyclone® 10 GX FPGA, Stratix® 10 AX SoC FPGA, Stratix® III FPGA
Offering Status	Production
Integrated Testbench	Yes
Evaluation License	Yes
Design Examples Available	Yes
Demo	No
Compliance	Yes
Latest Quartus Version Supported	25.1.1
Development Language	Encrypted Verilog, Verilog
