XIP1113B: AES256-GCM IP core

Overview Key Features Offering Brief What's Included Ordering Information Markets

Xiphera Ltd.

Select

Balanced speed AES256-GCM core implements the Advanced Encryption Standard (AES) in Galois Counter Mode (GCM) with few Gpbs linerates. AES-GCM is a widely used cryptographic algorithm for Authenticated Encryption with Associated Data (AEAD) purposes, providing both data confidentiality and authenticity.

View Partner Website

Partner Product Page

Contact Now

Contact Xiphera Ltd.

LeadSource

ASAP Account ID

Record Type Name

Key Features

Compact resource requirements: The entire XIP1113B requires 3571 Adaptive Lookup Modules (ALMs) (Altera® Agilex® 7 I), and does not require any multipliers, DSPBlocks or internal memory1 in a typical FPGA implementation.
Performance: Despite its compact size, XIP1113B achieves a throughput in the Gbps range2, for example 4.44+ Gbps in AMD® Kintex® UltraScale+.
Standard Compliance: XIP1113B is fully compliant with both the Advanced Encryption Algorithm (AES) standard [2], as well as with the Galois Counter Mode (GCM) standard [3]
Test Vector Compliance: XIP1113B passes all test vectors specified in [1].
Flexible Interfaces ease the integration of XIP1113B with other FPGA logic and/or control software.

Offering Brief

Device Family	Arria® 10 SX SoC FPGA, Cyclone® IV GX FPGA, Agilex® 5 FPGAs and SoC FPGAs E-Series, MAX® 10 FPGA, Cyclone® V SX SoC FPGA, Arria® V GZ FPGA, Agilex® 9 FPGAs and SoC FPGAs Direct RF-Series, Agilex® 7 FPGAs and SoC FPGAs I-Series, Arria® V SX SoC FPGA, Stratix® 10 DX FPGA, Stratix® 10 SX SoC FPGA, Agilex® 7 FPGAs and SoC FPGAs M-Series, Cyclone® V GT FPGA, Arria® 10 GT FPGA, Arria® V ST SoC FPGA, Arria® 10 GX FPGA, Stratix® 10 TX FPGA, Cyclone® V SE SoC FPGA, Stratix® IV E FPGA, Stratix® IV GX FPGA, Arria® V GX FPGA, Agilex® 3 FPGAs and SoC FPGAs C-Series, Cyclone® V GX FPGA, Stratix® V GS FPGA, Stratix® V GX FPGA, Cyclone® V ST SoC FPGA, Agilex® 5 FPGAs and SoC FPGAs D-Series, Stratix® 10 GX FPGA, Arria® V GT FPGA, Cyclone® 10 LP FPGA, Agilex® 7 FPGAs and SoC FPGAs F-Series, Cyclone® 10 GX FPGA, Stratix® 10 AX SoC FPGA, Stratix® III FPGA
Offering Status	Production
Integrated Testbench	Yes
Evaluation License	Yes
Design Examples Available	Yes
Demo	No
Compliance	Yes
Latest Quartus Version Supported	25.1.1
Development Language	Encrypted VHDL, VHDL
