Proc10A-40GigE: 40GigE Vision Frame Grabber\Smart NIC

Overview Key Features Offering Brief What's Included Ordering Information Documentation & Resources Markets

Gidel

Select

The Proc10A-40GigE Frame Grabber\smart NIC is ideal for high bandwidth applications, including multi-cameras and ultra-high bandwidth camera applications. Its high acquisition and processing capabilities ensures zero frame loss while offloading the CPU for key processing tasks.

View Partner Website

Partner Product Page

Contact Now

Contact Gidel

LeadSource

ASAP Account ID

Record Type Name

Key Features

Acquisition from up to 4 x 10 GigE Vision cameras
Zero frame loss with almost zero CPU utilization
Ideal for Recording & Streaming solutions
Inline Image Processing option
On-FPGA real-time Compression (Quality+, .jpg, lossless) Option
Real-Time High Dynamic Range (HDR) correction option
Supports 100+ synchronized cameras using the InfiniVision
On Board Memory: up to 33 GB
Support Link Aggregation and Chunk data
Passive cooling | Active cooling (fan)

Offering Brief

Device Family	Arria® 10 GX FPGA
Offering Status	Production
Device OPN(s) on Board	10AX027H3F34I2SG;10AX115H3F34I2SG;10AX066H3F34E2LG
Demo	No
Form Factor	Half-profile PCIe card (Gen. 3x 8)
Power	8-35W: Depends on user application and FPGA Type
Interfaces	4 x 10 GigE Cameras 8 x 5 GigE Cameras 16 x 2.5 GigE Cameras 30 x 1 GigE Cameras
Memory	256MB
Connectors	QSFP+ (Copper / Fiber optic) \| JTAG \| VGA15-pin for connecting GPIO's to the bracket \| 16-pin board-to-board header
Switches & LEDs	power, status LEDs
Latest Quartus Version Supported	20.4.0
