Logic Fruit Technologies has designed JESD204B RTL IP. It can support increased lane rates up to 12.5Gbps for higher bandwidth applications. It can be configured to transmit or receive using a 8B10B link layer to achieve deterministic latency, SerDes synchronization, clock recovery and DC balance.
Logic Fruit Global Technologies Inc
Key Features
- Applicable in RADAR, Medical Imaging as it supports higher bandwidth and more number of channels with fewer pins to simplify layout.
- Applicable in Wireless Communications, TDMA & OFDM based technologies such as LTE, WiMAX.
- Provides reduced PCB area and package size.
- Comparable power for large throughput.
- Provides interface for serializing devices from some system designs, reducing space, power, and cost.
- Mechanism to achieve Deterministic latency across the serial link.
Offering Brief
Offering Brief
| Device Family | Arria® 10 SX SoC FPGA, Arria® 10 GT FPGA, Arria® V GZ FPGA |
|---|---|
| Offering Status | Production |
| Integrated Testbench | Yes |
| Evaluation License | No |
| Design Examples Available | Yes |
| Demo | No |
| Compliance | No |
| Latest Quartus Version Supported | 24.3.1 |
| Development Language | VHDL |
VHDL Design Files
VHDL Test Bench
VHDL Test Cases
Log Files of Simulation Results
